TSURUMI KTV Series submersible pumps are lightweight, portable, and designed for three-phase dewatering applications. Despite being three-phase pumps, they are engineered for easy transportation and handling. Ideal for general construction and foundation works, the top discharge and side flow design ensure efficient motor cooling, even when operating in air. Additionally, the compact and slim structure allows installation in confined spaces.
Key Features:
- Lightweight & Portable
The compact and lightweight construction enables easy transport and installation. - Efficient Motor Cooling
The top discharge and side flow design keep the motor cool, even when exposed to air. - Wear-Resistant Materials
Impeller and pump casing are made from highly durable materials for extended service life. - Slim & Space-Saving Design
Allows installation in tight spaces with ease.
Recommended Applications:
- General construction and foundation dewatering
Drainage in confined spaces
Pumping water with sediment or suspended particles
TSURUMI KTV Series Submersible Pump Specifications
| Discharge Bore mm. |
Model | Motor output Kw. |
Phase | starting Method |
Solid Passage mm. |
Dimensions L x H mm. |
Dry Weight Kg. |
Cable Length m. |
| 50 | TSURUMI KTV2-8 | 0.75 | Three | D.O.L | 8.5 | 200×369 | 11.5 | 5 |
| 50(80) | TSURUMI KTV2-15 | 1.5 | D.O.L | 8.5 | 240×396 | 21 | 8 | |
| 50(80) | TSURUMI KTV2-22 | 2.2 | D.O.L | 8.5 | 240×416 | 23 | 8 | |
| 50 | TSURUMI KTV2-3H | 3.7 | D.O.L | 8.5 | 285×510 | 36 | 8 | |
| 80(100) | TSURUMI KTV2-37 | 3.7 | D.O.L | 8.5 | 285×510 | 36 | 8 | |
| 80(100) | TSURUMI KTV3-55 | 5.5 | D.O.L | 8.5 | 300×545 | 47 | 8 |
