TSURUMI BZ Series
TSURUMI BZ Series submersible pumps are designed for high-efficiency wastewater and sewage pumping. Here are the key features of this series:
Key Features:
- Impeller Design:
The pumps feature a channel impeller with a wide passage (over 3 inches / 76.2 mm), which helps to minimize clogging issues from solids and fibers in the water. - High Efficiency:
The BZ Series pumps are highly efficient, especially for motor power ranges from 22 to 75 kW, ensuring effective performance in demanding conditions. - Durable Material:
The pump body is made of high-quality cast iron, offering resistance to wear and corrosion for long-lasting performance. - Motor Protection:
The pumps are equipped with a motor protection system, preventing damage from issues like dry running or power surges.
Applications:
- Wastewater Treatment Plants:
Ideal for pumping wastewater in treatment processes. - Chemical Industries:
Used for handling wastewater containing chemicals or acids. - Food Industries:
Suitable for managing corrosive wastewater from food production processes.
TSURUMI BZ Specifications
| Model | ท่อทางออก | Motor | Speed | Motor Start System | Solids Passage |
Cable Length |
| mm | kW | min-1 | mm | m | ||
| TSURUMI 80BZ41.5 | 80 | 1.5 | 1500/1800 | D.O.L. | 80 | 6 |
| TSURUMI 100BZ42.2 | 100 | 2.2 | 1500/1800 | D.O.L. | 80 | 6 |
| TSURUMI 100BZ43.7 | 100 | 3.7 | 1500/1800 | D.O.L. | 80 | 6 |
| TSURUMI 100BZ45.5 | 100 | 5.5 | 1500/1800 | D.O.L. | 80 | 8 |
| TSURUMI 100BZ47.5 | 100 | 7.5 | 1500/1800 | D.O.L. | 80 | 8 |
| TSURUMI 100BZ411 | 100 | 11 | 1500/1800 | star -Delta | 80 | 10 |
| TSURUMI 100BZ411H | 100 | 11 | 1500/—- | star -Delta | 80 | 10 |
| TSURUMI 100BZ415 | 100 | 15 | 1500/1800 | star -Delta | 80 | 10 |
Dimensions
| Model | Dimensions (Length x Height) (mm) | Weight (kg) |
| Standard Model | Standard Model | |
| TSURUMI 80BZ41.5 | 523×631 | 78 |
| TSURUMI 100BZ42.2 | 551×632 | 80 |
| TSURUMI 100BZ43.7 | 584×681 | 100 |
| TSURUMI 100BZ45.5 | 716×925 | 175 |
| TSURUMI 100BZ47.5 | 716×946 | 194 |
| TSURUMI 100BZ411 | 727×1023 | 219 |
| TSURUMI 100BZ411H | 727×1023 | 219 |
| TSURUMI 100BZ415 | 845×1160/770×1088 | 297 |
